    Oil Diamond Drilling Tool 5-1/2inch PDC Drill Bit Of API Spec

    Ask Lasest Price
    Brand Name : ENG
    Model Number : 55000
    Certification : API, AISI, ISO
    Price : USD 2000-20000 Unit
    Payment Terms : L/C, T/T
    Supply Ability : 5000 PCS / Year
    • Product Details
    • Company Profile

    Oil Diamond Drilling Tool 5-1/2inch PDC Drill Bit Of API Spec

    Oil Diamond Drilling Tool 5-1/2inch PDC Drill Bit Of API Spec


    1 . Production Name :


    PDC Drill bit , PDC Bit ,Diamond PDC Bit , PDC Diamond Bit ,Rock Drill Bit , Drilling Rig Bit ,Diamond Drill Bit ,Well Drilling Bit , Drilling Rod Bit

    Mining Drill Bit ,water Drill Bit ,oil Drill Bit ,underground mining Drill Bit

    Diamond Drill tool ,Drilling Rig Tool ,


    Descriptions:


    PDC Drill bit , PDC Bit ,Diamond PDC Bit , PDC Diamond Bit ,Rock Drill Bit , Drilling Rig Bit ,Diamond Drill Bit ,Well Drilling Bit , Drilling Rod Bit

    Mining Drill Bit ,water Drill Bit ,oil Drill Bit ,underground mining Drill Bit

    Diamond Drill tool ,Drilling Rig Tool ,


    Utilizing "Polycrystalline Diamond Compact" (PDC) technology, the Diamond PDC bit enhances the efficiency and durability of drill bits in oil drilling operations significantly.


    The S616 PDC drilling bit serves as a prime example of excellence, functioning seamlessly as a fixed-head tool that ensures consistent and reliable performance throughout drilling activities.


    When selecting a PDC drill bit, essential factors like cutter density, size, bit design, and blade type are crucial determinants of performance across a range of drilling conditions.


    Our collection of PDC bits strictly adheres to API standards, guaranteeing smooth compatibility with drilling processes. Available in sizes from 3 to 22 inches with 3 to 9 blades, these bits offer diverse cutter classifications tailored to specific needs and budgets.



    2. Specification:


    PDC bits such as the S616 or M616 are specified with a 6-blade steel or matrix body and a 16mm main cutter. The IADC code indicates whether the bit is suitable for hard, soft or specific profile formations, providing additional insight.

    So the IADC 323 have different mean of the PDC drill bit.


    SPECIFICATION
    Size :5-1/2inch (139.7mm)
    Drill Body Type :Steel Body
    Blades Quantity :6
    Nozzles Quantity :3
    API Connection (in) :2-7/8" REG
    Gauge Length (In):1.5
    OPERATIONAL PARAMETERS
    Weight on Bit (KN):9-67
    RPM Range(Rotary):100- DHM
    Flow Rate(lps):11- 15 LPM
    Make-Up Torque(KN):9.5-12.2 KN.M


    3 . PDC Drill Bit profile


    4 . Drill Bit PDC Cutters


    At the heart of a drill bit are polycrystalline diamond composite (PDC) cutters, which engage directly with the rock, using primarily shearing action for removal. In the demanding environment of a well, PDC cutters undergo frequent heating and cooling cycles, which pose significant challenges.

    PDC cutters with improved thermal stability and reduced thermal degradation tend to perform better, resulting in higher rates of penetration (ROP) and improved wear resistance. Optimising these cutters is therefore critical to maximising effiency.



    5. PDC Drill Bit Nozzles


    PDC Drill bit nozzles help clear the cutting area and cool the Polycrystalline Diamond Composite (PDC) cutters.

    Effective placement of these nozzles along with the angle they are set at plays a critical role on how efficient the drill bit performs.

    Fluid channels also complement nozzle placement to improve the clearing of cuttings.


    6. Steel Body PDC Bits


    Material Capacity & Following Standard


    APIISOASMNACE
    API Spec 7-1ISO 9001ASME B94.55M ASME B94.11MNACE

    The steel materials of PDC Drill Bit is AISI 4145H alloy structural steel .


    ‌AISI 4145H alloy structural steel‌: This is a steel specifically used for oil drilling tools, especially for the manufacture of heavy-duty drill pipes. AISI 4145H steel has good wear resistance and toughness, can withstand high pressure and high temperature environments, and is suitable for deep and ultra-deep well drilling operations‌45.


    Material Composition :


    CompositionC(%)Si(%)Mn(%)P(%)S(%)Cu(%)Cr(%)V(%)Mo(%)Al(%)Ti(%)
    SAE4145HS452611020211150.932204.2

    Steel body of PDC Bit is the opposite of matrix body. It can of withstanding high impact loads, but is softer and lacks protective features. The strength and ductility of steel give steel-bit bodies high impact resistance.

    Steel bodies are considerably stronger than matrix bodies.

    A beneficial feature of steel bits is that they can easily be rebuilt a number of times because worn or damaged cutters can be replaced rather easily. This is a particular advantage for operators in low-cost drilling environments.


    Polycrystalline diamond compact (PDC) drill bits are different than roller cones in that they are one piece bodies with no moving parts. The fixed-cutters shred the rock, so the bit is able to operate with higher rotation speeds more efficiently in consolidated formations.
