Diamond Core Drill Bit 8 Inch PDC Fixed Cutter Bit Of PDC Core Bit

Description :

There are six different types of oilfield PDC core bits that can be manufactured depending on the application and the cutting media used on the PDC core bits:

• Impregnated Diamond Type oilfield PDC bits
• Surface set diamond type oilfield PDC bits
• Tungsten Carbide Type oilfield PDC bits
• PDC type oilfield PDC bits
• PCD type oilfield PDC bits
• Electroplated diamond type oilfield PDC bits

A complete drilling system typically consists of drill rods, core bits, reaming shells, core barrels and drill rig.

Core bits are used to drill materials such as rock, concrete, limestone, granite, marble, clay, basalt, shale and quartz.

Oilfield PDC Core Bit Specification:

- Oilfield PDC Core Bit are used from soft to medium formations like chalk, sand, shale, anhydrite, marl, and salt.

- PDC cutters are 13mm Of oilfield PDC Core bit

- A rounded profile of Oilfield PDC Bit

- Gages for natural diamonds of Oilfield PDC Bit

- Body made of tungsten carbide of oilfield PDC Bit

3. Oilfield PDC Bit profile.

Oilfield Core PDC drill Bit has a shallow parabolic profile and medium cutter density, designed for coring the medium hard

formation . Utilizing different patented PDC cutters enhance the oilfield bit’s ability to drill in hard formations.

High quality TSP in the inner blade and gauge has high wear-resistant for longer Oilfield PDC bit life.The uniquenozzle design improved the cleaning and cooling ,enhanced the ability cuttings evacuation.

4 .Drill Bit Choose

For oilfield PDC core Bit drilling materials including rock, concrete, limestone, granite, marble, clay, basalt, schist, and quartz, among others, core bits are employed.

all the series and type core drill are as below , you can choose and you can contact with us to know more about them .

Suzhou Energy Tool Co., Ltd . (short for “ENG ” ) is a high-tech company formed by a group of drill bit experts with over 20 years of work experience in the world's top oil service companies. ENG has cooperated with many research institutes at home and has formed an advanced technological system based on market-oriented and continuously promoting technological innovation and product improvement. ENG‘S bits production lines are equipped with 5-axis machining centers, Modern lathes, and FMS (Flexible manufacturing system ) and can produce matrix body and steel body PDC bits from 3-1/4” to 26” in diameter.

ENG has been keeping on  producing high-quality products to meet the buyer diffferent requirement of different drilling well and rock fromation . The company’s QMS has been award  API, ISO 9001 certification for many years. ENG has Obtained  21 patents by Chinese government .On the products Research and Development, ENG has built the basis of 3-dimensional CAD and PDM (Product Data Management ), can technically control the whole process of product manager, so that the product development can be done in a fast and precise manner to maximally meet the time and function requirement of the market for product lifecycle management.

ENG developed different performance series PDC cutters for PDC bit to meet different drilling applications and drilling requirements of different formations. Some PDC Cutter is imported from the USA Or Europe. ENG's advantage is high product quality, short delivery time, small lot, and multi-types. The products have been exported to over 10 countries Such as the USA, Australia, Indonesia, Thailand, Malaysia, Indonesia, Argentina, and so on.
